A signal source can be displayed on the M ? N (M e 1, N e 1) display units
Multiple signal sources are supported, including VGA, DVI, HDMI, SDI, YpbPr, DP, HDBaseT. Up to 3840 ? 2160@30 Hz resolution is supported for HDMI, DP and HDBaseT signal inputs.
Distributed network signal sources configurable to raise the signal source capacity and transmission distance
Live view in the roaming window and live view list
Fluent video output without frame extraction to guarantee the lossless output of 60 frames
An enhanced network decoding board supports H.264 and H.265 compression standard and can display network signal of 2-ch@8.0 MP, 2-ch@6.0 MP, 2-ch@5.0 MP, 8-ch@1080p, 16-ch@720p and 32-ch@D1 and local video files
Auto sub-stream decoding if the output resolution of decoding window is lower than 640 ? 640
Tile mode available and the video layers can be extended to 8 layers in tile mode
Supports 1/4/9/16 window division modes and full-screen switch of the window. (Unavailable for the LED mode)
The window can be kept sticking on top without being affected by the operations of other windows and kept open without being affected by the scene or plan configuration
Up to 6 image layers can be displayed on one screen, including one virtual LED image layer and a background layer
The LED background color is adjustable. The resolution of background layer is up to 8192 ? 8192
The tile mode can be saved in the scene
Video wall mirror configurable to mirror the content of one video wall area to another area
Users have the permission to manage the signal sources and video wall.
